2515MHz-2675MHz 31W Final Solution

应用方案 | 日期：2022-09-23 | 阅读：


2515MHz-2675MHz 31W Final Solution(图1)


FinalDXG1CH27A-200EF
2515MHz-2675MHz 31W Final Solution(图2)
Package Type: 780-4




CW Pulsed 10%


Modulated  Signal

Freq (MHz)

Psat (dBm)

Gp (dB)@45dBm

DE (%)@45dBm

ACLR (dBc)@ 45dBm

251554.014.8

49.5

-30.0

259553.814.950.8-33.0
267553.314.549.6-33.0


Remark : Test  ConditionCW Pulsed: 10% Duty Cycle, 100uS Duration; Modulated Signal Type: 3.84MHz, 1C_WCDMA, PAR=7.8dB; 64DPCH;Tested without isolator.
