2110MHz-2170MHz 10W Final Solution

应用方案 | 日期：2022-09-23 | 阅读：

2110MHz-2170MHz 10W Final Solution(图1)Final:DXG1CH19A-100EF
2110MHz-2170MHz 10W Final Solution(图2)
Package Type: 400-4




CW Pulsed 10%


Modulated  Signal

Freq (MHz)

Psat (dBm)

Gp (dB)@41.7dBm

DE (%)@41.7dBm

ACLR (dBc)

@ 41.7dBm

211050.41758.5-34
214050.316.959.2-33.8
217050.316.758.5-33.5


Remark : Test  ConditionCW Pulsed: 10% Duty Cycle, 100uS Duration; Modulated Signal Type: 3.84MHz, 1C_WCDMA, PAR=7.8dB; 64DPCH;Tested without isolator.
